DN100 Electromagnetic flow meter KLD PN16 (distiller’s grains), 100 m3/h, 4-20mA, Ex
Documentation
Download instructions, catalog for DN100 Electromagnetic flow meter KLD PN16 (distiller’s grains), 100 m3/h, 4-20mA, Ex
Overview
The measuring principle of electromagnetic flow meter is based on Faraday's law of electromagnetic induction. The sensor is mainly composed of a measuring tube with an insulated lining, a pair of electrodes installed by penetrating the wall of the measuring tube, a pair of coils and an iron core to generate a working magnetic field. When a conductive fluid flows through the sensor's measuring tube, a voltage signal directly proportional to the average fluid flow rate will be induced at the electrodes. The signal is amplified and processed by the transmitter to realise various display functions.
Characteristics
| Flow range | 100m3/h |
| Control signal, mA | 4-20 |
| Type of flow meter | electromagnetic |
| Voltage, V | 24 |
| Connection diameter, DN | 100 |
| Producer | BTS Engineering |
| Explosion protection | Yes |
| Connection type | flanged |
| Max.temperature, C | 130 |
| Housing material | carbon steel |
| Material of lining | PTFE |
| Country of Origin | China |
| Gross weight, kg | 19 |
| Length of transport packing, cm | 310 |
| Width of transport packing, cm | 300 |
| Height of transport packing, cm | 480 |
