Monoblock irrigation pump ETKF-M 32-250, 15 kW, 3000
Also buy with this product
1042539
Pre-order only
Documentation
Download instructions, catalog for Monoblock irrigation pump ETKF-M 32-250, 15 kW, 3000
Overview
ETKF-M centrifugal monoblock pumps with a coupling connection are designed for pumping non-abrasive clean and conditionally clean liquids. The pump dimensions comply with the TS EN 733 standard. The suction and discharge flanges comply with the ISO 7005-2/PN 16 standard. Sealing of the working chamber is provided by a mechanical seal. A closed impeller is used.
Application: agricultural irrigation and sprinkling; heating and cooling systems; fire extinguishing systems; for drainage, and other industrial purposes.
Technical data: discharge flange: DN32 ... DN150. Capacity: up to 550 m3/h. Height: 105 m. Speed: 1450-3600 rpm (50 Hz-60 Hz). Operating temperature: -10°C ' to +105°C. Housing pressure (Pmax): 10 Bar (16 bar).
Characteristics
| Producer | ERDURO |
| Pump capacity, m3/h | 32 |
| Feed height, m | 100 |
| Power capacity, kW | 15 |
| Material | cast iron |
| Input pipe diameter | DN50 |
| Output pipe diameter | DN32 |
| Rate of turn, rpm | 3 000 |
| Power supply | 3х380 V, 50 Hz |
| Explosion protection | No |
| Max.flow rate, m3/h | 32 |
| Max.temperature, C | 100 |
| Impeller diameter, mm | 264 |
| Seal | Mechanical Seal |
| Max. head, m | 100 |
| Housing material | Сast iron |
| Impeller material | cast iron |
| Serial number of the pump | ETKF-M |
| Country of Origin | Turkey |
| PumpType | console |
| Drive Type | electric |
| Installation Type | horizontal |
| Type of configuration | with engine |
| Application | water, cooling tower, ice water, water recycling, heating, increasing pressure, glaze, the drying chamber, drying, circulation |
| Analogue for | Speroni CS, Speroni MEM, Speroni CFM, Ebara 3D, Pedrollo HF, CALPEDA NM |
| Weight, kg | 142 |
