ProducerDiaPump
Pump capacity, cu.m/hour9.6
Feed height, m80
MaterialAISI 316L
Serial number of the pumpDP
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order only
Vendor code: 1020096
Specify the price and terms of delivery with the manager

Estimated delivery date: 23.05.2024

$2,102.68netto
-+Buy

Documentation

Download instructions, catalog for DP 10 SC/SN - SC/N - SC/B - Pneumatic Membrane Pump

Overview

Dia Pump
Membrane pumps DP with innovative air separation system, geometry of pump chambers and valve system, allows to pump over a wide range of aggressive products (concentrated acids, alkalis, solvents, laquers, glues, liquids with suspended particles to 10 mm, abrasive products, etc.) with viscosity from 6000 to 55000 cPs. Wet part of membrane pumps DP is made of such material as: - РР: POLYPROPLENE ; - PB: FIBER POLYPROPLENE; - PVDF: KYNAR; - AL: ALUMINUM; - DD: CAST IRON; - SC: АІSI 316L; - SS: АІSI 316. The main working bodies (membranes, ball valves, ball seats) are made of: - S: SANTOPRENE; - N: NEOPRENE; - B: BUNA-N (NBR); - E: EPDM; - T: PTFE; - V: VITON / FKM. The advantages of pneumatic membrane pumps DP: - Dry self-suction to 6 m; - Self-suction with flooded suction to 9,8 m; - Unrestrained dry running.

Characteristics

ProducerDiaPump
Pump capacity, cu.m/hour9.6
Feed height, m80
MaterialAISI 316L
Serial number of the pumpDP
Country of OriginTurkey
Explosion protectionYes
ATEX standardEx II 2 G c Tx; Ex II 2 D c Tx; Ex I M2 c T (150°C)
PumpTypemembrane pneumatic
Drive Typepneumatic
Dry suction height, m6
Suction capacity (NPSH), m9,8
Max.flow rate, m3/h9.6
Noise level ,dB65
Max.viscosity, cPs35 000
Diametr of the product line1"
Max. head, m80
ModelDP 10
Flow rate, l/min160
Max.air pressure, bar8,4
Diameter of the pneumatic mainline1/2"
Max.temperature, C95
Max.diameter of solid inclusions, mm4
Weight, kg12
Material of flow channelAISI 316L
Diaphragm material at water sideNEOPRENE-BUNAN
Availability of spare partsyes
Warranty, months12
Applicationnitric acid, ammonia, butane, hydrogen, viscous liquids, clays, ash, kaolin suspension, urea, carbonate, paints, varnish, saturated amine, oleum, peroxide, sulfur, reverse osmosis systems, alcohol, acetic acid, phenol, formalin, phosphates, phosphoric acid, slag, slip, alkalis, ethylene, ethers
Analogue forAGRAL DDE-030, AGRAL DDE-100, AGRAL DDE-160, AGRAL DDE-300, AGRAL DDE-60, AGRAL DDE-600, AlphaDynamic Ruby, AQUA, AquaViva, Astralpool, Debem BOXER, Debem FOODBOXER, Debem SANIBOXER, DELLMECO DM, DELLMECO DMCX, DEPA DB, DEPA L, DEPA М, DEPA РМ (Р), DOSITEC, Duotek AF Zone 2 Atex, DUOTEK FOOD, DUOTEK SANI, Emec, FWT, Graco Husky, Grundfos, Injecta, Jesco Pump, MILTON ROY, Milwaukee, PRODOSE, ProMinent, Seko, Sera, WILDEN, YAMADA NDP

Categories:Diaphragm pumpsNitric acid pumpPump for liquid glassPump for cream and pastePumps for viscous liquidsGlycerin pumpsAcid pumpsGlue pumpsPumps for paints and varnishesPumps for an ice creamVegetable oil pumpsResin pumpsPumps for freonLye pumpsAcid-resistant pumps for aggressive liquidsDiaphragm pumps FDAPumps for aggressive liquids, acid pumpFood pumpsPneumatic Pumps
