Mechanical sealsMechanical seals
Shaft materialCERAMIC
ProducerBTS Engineering
Max.temperature, C70
Max.flow rate, m3/h27
Max. head, meter of water column24.4
All specifications
Pre-order only
Артикул: 1022560
$3,766.32
-+Купить
  • Overview
  • Characteristics
  • Reviews0
BTS Engineering
Chemical pump for alkali, acid, filtration, electroplating, hypochloride, nitric acid. Magnetic coupling pumps, unlike other chemical pumps, have a significant feature - the design of these pumps does not use a mechanical seal, oil seal or other sealing element of this type. The drive of the working body is carried out by means of a magnetic field, the working chamber and the drive shaft are separated by a fixed casing made of chemically stable material. This eliminates the possibility of liquid leakage from the working chamber. The magnetic coupling is not afraid of solid particles in the liquid, there is no possibility of leakage, which is not unimportant when pumping chemically active and explosive liquids. Unlike pumps with mechanical seals, pumps equipped with a magnetic coupling do not require maintenance (which leads to cost and time savings). Technical Specifications: Inlet-outlet pipe: 50x40 mm Engine: TOSHIBA Motor power: 1.5 kW Power Supply: 50HZ 380-380V Feed height (max): 24.4 m Capacity (max): 450 l / min Pump analogues: - AGRAL series TMB, TMP, TMR, FLUIMAC Series CM, IWAKI, Finish Thompson Ins, Kaix series MDP, Gemme Cotti Series HTM, Crystal Series HCM, M Pumps series CM MAG-P
Shaft materialCERAMIC
ProducerBTS Engineering
Max.temperature, C70
Max.flow rate, m3/h27
Max. head, meter of water column24.4
PumpTypewith magnetic coupling
Installation Typehorizontal
Material of ball valvesVITON(FKM)
Input pipe diameter50
Power supply3х380 V, 50 Hz
Drive Typeelectric
Power capacity, kW1,5
MaterialCFRETFE
Output pipe diameter40
Weight, kg25,7
Serial number of the pumpMP-HX
Pump modelsMP-HX-542
Dimensions, mm536x286x261
Analogue forAGRAL TMB, AGRAL TMP, AGRAL TMR, FLUIMAC CM, IWAKI, Finish Thompson Ins, Kaix MDP, Gemme Cotti HTM, Кристалл ХЦМ, M Pumps CM MAG-P, DB, SP, EVT, STEIN

MP-HX-542 CFRETFE, 450L/min, 24.4m, 380V-TOSHIBA pump with magnetic coupling reviews

Categories:Magnetic Drive PumpsPump with magnetic coupling MP-HX
