ProducerDEBEM
Pump capacity, cu.m/hour13
Feed height, m13.8
MaterialPVDF
Serial number of the pumpDM
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order only
Vendor code: DM10FC-SD1NE071
Specify the price and terms of delivery with the manager

Estimated delivery date: 24.05.2024

$1,559.94netto
-+Buy

Overview

DEBEM
DM canned pumps without seals and magnetic couplings. Hermetic pumps with a magnetic coupling used for pumping corrosive, toxic or inflammable liquids, and liquids containing particles. Several magnets drives the pump in motion, the external magnet located on the shaft, transmits the motion to the inner magnet embedded in the impeller, which is hermetically isolated. The impeller is mounted on the pump shaft, therefore, no seal, which prevents leakage of the pumped fluid as a consequence of the seals wear. Pump head consists of several components, simplifying thus maintenance. Standard pump performance materials: polypropylene (PP) and polivinilindenftorid (PVDF). These pumps can not run "dry". Pumping contaminated liquids leads to a reduction of pump service life.

Characteristics

ProducerDEBEM
Pump capacity, cu.m/hour13
Feed height, m13.8
MaterialPVDF
Serial number of the pumpDM
Country of OriginItaly
Input pipe diameter1 1/2”
Output pipe diameter1”
Power capacity, kW0,55
Power supply3х380 V, 50 Hz
PumpTypewith magnetic coupling
Drive Typeelectric
Max.medium temperature, Celsius degree95
SealNo
Impeller diameter, mm98
Max.flow rate, m3/h13
Material of O-ringEPDM
Max.viscosity, cPs150
Max. head, m13.8
ModelDM10
Max.temperature, C95
Weight, kg9
Material of flow channelPVDF
Availability of spare partsyes

Categories:Chemical magnetic pumpsHermetic pumpsCentrifugal pumpsNitric acid pumpAcid pumpsLye pumpsAcid-resistant pumps for aggressive liquidsPumps for aggressive liquids, acid pumpElectroplating pumpsMagnetic Drive Pumps DM
