ProducerROVATTI
Pump capacity, cu.m/hour54
Feed height, m148.8
Materialcast iron
Serial number of the pumpTK
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order only
Vendor code: 80414815
Specify the price and terms of delivery with the manager

Estimated delivery date: 23.05.2024

$5,640.20netto
-+Buy

Overview

ROVATTI
ROVATTI Pump driven by a tractor PTO Rovatti pumps of the T2K, T3K series are multi-stage, cantilever pumps driven by a tractor PTO. The impellers of the pump are fixed on the high-speed shaft of the multiplier, which increases the speed of rotation of the working bodies to the required ones. Pumps of this type are designed to supply a large volume of water under significant pressure. These pumps are used when it is necessary to transport water over long distances, for sprinkler irrigation, for fire fighting, for filling containers, for supplying carbamido-ammonia mixtures. Characteristics of Rovatti series T2K, T3K Capacity-up to 90 cubic meters. in an hour Pressure-up to 17 ATM Material of execution of the flow Part-cast iron

Characteristics

ProducerROVATTI
Pump capacity, cu.m/hour54
Feed height, m148.8
Materialcast iron
Serial number of the pumpTK
Country of OriginItaly
Input pipe diameter65
Output pipe diameter50
PumpTypepowered by a PTO
Drive Typemechanical from PTO
The capacity of the shaft, k.s.46,8
Max.flow rate, m3/h54
Max. head, m148.8
Tractor power min, hp55,8
The rotary speed of PTO, rpm545
Material of flow channelcast iron
Warranty, months12
Applicationreservoirs filling, tanks filling, extinguishing, glaze, spraying liquid fertilizer
Analogue forBBA pumps, Caprari, Comet, Ekler, FAMOS, GEA, GPA, Kömag, Svahen, VARISCO, Yuzuak Sprinklers Irrigation, ОМЗ Пинск

Categories:PTO driven pumpPumps for ammonia water, ammonium hydroxide NH4OHPTO-driven irrigation pumpsROVATTIPTO pumps from the tractor drive of company ROVATTTractor PTO pumps
