Timer dosing block BioClean Control 0101 Santoprene
Also buy with this product
1042539
Pre-order only
Documentation
Download instructions, catalog for Timer dosing block BioClean Control 0101 Santoprene
Overview
BIOCLEAN CONTROL - a series of peristaltic pumps complete with an electronic timer.
Pumps are designed to dispense chemical reagents over time, for example:
- hydrogen peroxide,
- sodium hypochloride,
- acids,
- coagulant / flocculant,
- detergents, etc.
The pump body is made of anti - acid plastic-GW PLAST©. The built-in digital timer has 8 cycles for daily or weekly operation programming.
Pump capacity up to 3 L/H , back pressure up to 3 Bar .
The main advantages of this series : compact size, light weight, quiet operation.
The intake height is 2m.
Characteristics
| Producer | ETATRON D.S. |
| Rate of turn, rpm | 20 |
| Power supply | 1х220 V, 50 Hz |
| Control | Manual |
| Power capacity, Wt | 3,5 W |
| Dosage mode: Continually ON-OFF | Yes |
| Input foe sensor | No |
| Dosage mode: proportional PROP | No |
| Input for sensor CD | No |
| Product regulation 0-100% | No |
| Input foe temperature sensor | No |
| Input for level sensor reagent | No |
| Input mA | No |
| Flow rate, l/h | 1.1 |
| Input 4-20 mA | No |
| Output service relay | No |
| Pulse input(From Flowmetwer) | No |
| Support for flow sensor | No |
| Hose standard size | 4x7 |
| Input foe sensor PH | No |
| Pressure, bar | 1 |
| Input for sensor RX | No |
| Material for working hoos | Santoprene |
| Serial number of the pump | Bioclean Control |
| Country of Origin | Italy |
| Availability of spare parts | Yes |
| Application | antisepsis, liquid powders, acid, coagulant, misalignment, chemistry, alkalis |
| Analogue for | AquaViva, ASeko, Descon trol S, Emec, FWT, Injecta, Seko |
