Dosing pump PDE DLX CD/M 5-7 230V/240V
Also buy with this product
1042539
Pre-order only
Documentation
Download instructions, catalog for Dosing pump PDE DLX CD/M 5-7 230V/240V
Overview
- Dosing pump with integrated CD (electrical conductivity) controller.
- Dosage regimens: proportional PROP. or constant ON / off.
- Measuring range 0-1.000 µs (K5) or 0-10.000 µs (K1).
- Backlit liquid crystal display.
- Five indicators for displaying the work status.
- 5 touch buttons for selecting pump operating modes.
- Output 4-20 mA.
- Support for Level Sensor (sensor not included).
Characteristics
| Producer | ETATRON D.S. |
| Material | PP |
| Power supply | 1х220 V, 50 Hz |
| Control | Microprocessing |
| Power capacity, Wt | 37 W 0,16А |
| Dosage mode: Continually ON-OFF | Yes |
| Input foe sensor | No |
| Length of a pistone stroke, mm | 0,69 |
| Model | CD/M |
| Dosage mode: proportional PROP | Yes |
| Input for sensor CD | Yes |
| Product regulation 0-100% | Yes |
| Input foe temperature sensor | No |
| Input for level sensor reagent | Yes |
| Input mA | Yes |
| Flow rate, l/h | 5 |
| Input 4-20 mA | No |
| Output service relay | No |
| Pulse input(From Flowmetwer) | No |
| Support for flow sensor | No |
| Input foe sensor PH | No |
| Pressure, bar | 7 |
| Input for sensor RX | No |
| Number of pulses | 120 |
| Pump body material | Polypropylene |
| Serial number of the pump | DLX |
| Country of Origin | Italy |
| PumpType | dosing solenoid |
| Drive Type | electric |
| Availability of spare parts | Yes |
| Application | algaecide, hypochlorite, caustic, acid, coagulant, of hydrochloric acid, alkalis |
| Analogue for | AquaViva, ASeko, Descon trol S, Emec, FWT, Injecta, Seko |
| Weight, kg | 2,3 |
