ProducerLEO
Pump capacity, cu.m/hour26
Feed height, m12
Serial number of the pumpWQ
Country of OriginChina
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order only
Vendor code: 7738113
Specify the price and terms of delivery with the manager

Estimated delivery date: 24.05.2024

$342.08netto
-+Buy

Overview

LEO
The submersible sewage electric pump for wastewater disposal is characterized by high efficiency in the most unfavorable conditions. The two-channel impeller provides high resistance against blockages, high hydraulic efficiency at high feeds, and stable operation without turbulent swirls. The pumps of this series are easy to install and maintain. It can be installed on an automatic quick-release coupling, or freely installed for mobile operation of the pump. The combination of a compact design with the possibility of high-pressure supply makes these pumps an ideal solution for Wells with both temporary and stationary installations. WQ series pumps are used for: - drainage of wetlands and irrigation of fields in agriculture; - earthworks; - fish farms; - drainage wells.

Characteristics

ProducerLEO
Pump capacity, cu.m/hour26
Feed height, m12
Serial number of the pumpWQ
Country of OriginChina
Output pipe diameterDN50
Power capacity, kW0,75
Power supply3х380 V, 50 Hz
PumpTypesubmersible drainage and fecal
Drive Typeelectric
Max.head, meter of water column12
Impeller materialcast iron
Max. head, m12
Max.pump flow, m3/h26
Max.temperature, C40
Material of flow channelcast iron
Applicationsewerage, KNS, diversion drains, treatment facilities, septic tank

Categories:Submersible drainage and fecal pumpsSewage and sewage pumpsPumps for SPS (sewage pumping stations)
