Industrial diesel generator XHYC-1000GF* with ATS, engine Cummins 1250kVA, 1000kW, 380V/50HZ open type
Documentation
Download instructions, catalog for Industrial diesel generator XHYC-1000GF* with ATS, engine Cummins 1250kVA, 1000kW, 380V/50HZ open type
Overview
XINHONGYUAN diesel generator with Cummins open-type engine. The generator includes ATS, which is a voltage monitoring system and automatic generator start in case of a power failure from the external power supply. The generator can be supplied in two versions: open and closed (silent). The diesel generator is suitable for industrial use as an emergency power source. It can be used to successfully maintain the infrastructure of public buildings, commercial and agricultural enterprises, as well as used as an emergency power supply system for buildings.
Characteristics
| Alternator model | HYF-1250 |
| Rated power, kW | 1 000 |
| Bore * stroke, mm | 159x159 |
| Generator type | open |
| Rated power, kVA | 1 250 |
| Engine manufacturer | Cummins |
| Frequency, Hz | 50 |
| Oil capacity, l | 135 |
| Fuel type | diesel fuel |
| Compression ratio | 14.5:1 |
| Engine model | KTA38-G9 |
| Fuel consumption, g/kW/h | 195 |
| Producer | XINHONGYUAN |
| Rated voltage, V | 380V |
| Model | XHYC-1000GF* |
| Dimensions, mm | 4950x2080x2560 |
| Country of Origin | China |
| Warranty, months | 12 months but not more than 1000 motor hours |
| Weight, kg | 7 200 |
