Alternator modelHYF-300
Rated power, kW250
Bore * stroke, mm116,5x148
Generator typeclosed
Rated power, kVA300
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order onlyItaly: Pre-order only
Vendor code: 1039905
Specify the price and terms of delivery with the manager

Estimated delivery date: 10.07.2025

$43,349.06netto
-+Buy

Documentation

Download instructions, catalog for Industrial diesel generator XHYC-250GF with ATS, engine Cummins 300kVA, 250kW, 380V/50HZ closed type

Overview

XINHONGYUAN
XINHONGYUAN diesel generator with a Cummins engine of closed type. The generator includes ATS - a voltage monitoring system and automatic generator start in case of a power failure from the external power supply. The generator can be supplied in two versions: open and closed (silent). The diesel generator is suitable for industrial use as an emergency power source. It can be used to successfully maintain the infrastructure of public buildings, commercial and agricultural enterprises, as well as used as an emergency power supply system for buildings.

Characteristics

Alternator modelHYF-300
Rated power, kW250
Bore * stroke, mm116,5x148
Generator typeclosed
Rated power, kVA300
Engine manufacturerCummins
Frequency, Hz50
Oil capacity, l35
Fuel typediesel fuel
Compression ratio16,6:1
Engine model6LTAA9.5-G3
Fuel consumption, g/kW/h197
ProducerXINHONGYUAN
Rated voltage, V380V
ModelXHYC-250GF
Dimensions, mm3010x1000x1700
Country of OriginChina
Warranty, months12 months but not more than 1000 motor hours
Weight, kg2600 (open)
