Industrial diesel generator XHYS-350GF with ATS, engine Kaipu 400kVA, 350kW, 380V/50HZ closed type
Documentation
Download instructions, catalog for Industrial diesel generator XHYS-350GF with ATS, engine Kaipu 400kVA, 350kW, 380V/50HZ closed type
Overview
XINHONGYUAN diesel generator with a closed-type Kaipu engine. The generator includes ATS - a voltage monitoring system and automatic generator start in case of voltage loss from the external power supply. The generator can be supplied in two versions: open and closed (silent). The diesel generator is suitable for industrial use as an emergency power source. It can be used to successfully maintain the infrastructure of public buildings, commercial and agricultural enterprises, as well as used as an emergency power supply system for buildings.
Characteristics
| Alternator model | HYF-400 |
| Rated power, kW | 350 |
| Bore * stroke, mm | 135x165 |
| Generator type | closed |
| Rated power, kVA | 400 |
| Engine manufacturer | Kaipu |
| Frequency, Hz | 50 |
| Oil capacity, l | 33 |
| Fuel type | diesel fuel |
| Compression ratio | 15.75:1 |
| Engine model | KP425 |
| Fuel consumption, g/kW/h | 210 |
| Producer | XINHONGYUAN |
| Rated voltage, V | 380V |
| Model | XHYS-350GF |
| Dimensions, mm | 3100x1400x1700 |
| Country of Origin | China |
| Warranty, months | 12 months but not more than 1000 motor hours |
| Weight, kg | 3300 (open) |
