Station 0.6kVt Qmax Hmax 35m 50L / min (samovsmok. Pump) 24l
Overview
Station 0.6kVt Hmax Qmax 50l 35m / min (samovsas. Pump) 24l LEO (776,201) Water Stations are equipped with a pressure accumulator 24 liters and control automatics. Stations intended for pumping clean water and can be used: for domestic water, auxiliary equipment, lifting the water in the low pressure piping systems for irrigation of gardens and gardens, greenhouses and greenhouses. The pressure switch controls the operation of the electric pump - the pressure switch setting is P (ON) 1.4 bar / R (off) 2.4 bar. Installation of the equipment must be carried out in places protected from the weather and moisture. Pumping Unit: - Housing: technopolymer; - Impeller: technopolymer; - Engine Shaft: Stainless steel AISI 304; - Accumulator: painted steel; - Automation: relays Pressure gauge included in the box. Motor: - Engine type: asynchronous closed type air cooling, with built-in thermal protection winding; - Bearings: rolling (C & U); - winding the stator to move in!
Characteristics
| Producer | LEO |
| Pump capacity, cu.m/hour | 3 |
| Feed height, m | 35 |
| Power capacity, kW | 0,6 |
| Input pipe diameter | G1 |
| Power supply | 1х220 V, 50 Hz |
| Max. head, m | 35 |
| Max.medium temperature, Celsius degree | 35 |
| Width, mm | 275 |
| Height, mm | 580 |
| The diameter of loaded solid particles, mm | 0.2 |
| Nom.head, m | 20 |
| Max.flow rate, m3/h | 3 |
| Length, mm | 460 |
| Country of Origin | China |
