Mechanical seal R-2100S 70, CAR/SIC, VITON, 304

ProducerBTS Engineering
Shaft diameter70
Rubber typeVITON
Material of metal part304
Stationary and rotating faceCAR/SIC
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order only
Vendor code: 13684_70__CAR/SIC__VITON__304
Specify the price and terms of delivery with the manager

Estimated delivery date: 23.05.2024

$292.04netto
-+Buy

Overview

BTS Engineering
Mechanical seal R-2100S is a compact modular type mechanical seal with a spring and one central elastomeric bellows ensures maximum efficiency and hardware work in all conditions. Used at a temperature of from -40 to + 120°C, a pressure up to 1, 2 MPa and the rotation speed to 15 m/sec. Used in compressors, centrifugal, rotary, turbine-type pumps: Gorman-Rupp, Ebara (3M), WILO, CP, CUP, CP, K, KM, KML, CP, X, AX, CS, CM. Analogues of mechanical seals: John Crane in 2100, 2100S, 2100K, AESSEAL B05U / B05, Flowserve Pac-Seal 140/142/143, ANGA A4 / A41, Vulcan Type 14/142/143, Sterling 540/542/543. Mechanical seal for Wilo pump, K, KM, X, AH, AHP, AH, Calpeda, DAB, Ebara, Grundfos, pump KSB, Allweiler, SALMSON, ACD Cryo, Flygt, IMP Pumps, LOWARA, PENTAX, Foras, Fristam, pump SPERONI, ZENIT, Inoxpa, JL, Johnson pump, KOLMEKS, Pedrollo, SAER, Vulcan, WQ, WQK, pump Tuchenhagen, ALFA LAVAL, Donjoy, Mission Magnum.

Characteristics

ProducerBTS Engineering
Shaft diameter70
Rubber typeVITON
Material of metal part304
Stationary and rotating faceCAR/SIC
Rotation velocity15 m/s
Pressure1,6 mPa
Operating temperature-20°C + 150°C
Seal typeR-2100S
ApplicationUnitech, VG, NCS, ONV, ONC
Analogue forHermetica M212.K, AESSEAL B05U, AESSEAL B05, Flowserve 140, John Crane 2100S, LIDERING LRB25, Sterling 540, US Seal G, Vulcan 14DIN
Length of transport packing, cm8
Width of transport packing, cm8
Height of transport packing, cm10
Gross weight, kg0.25

Video Mechanical seal R-2100S 70, CAR/SIC, VITON, 304

How to properly measure a mechanical seal
