Mechanical sealsMechanical seals
Gross weight, kg0.25
Operating temperature-20°C + 150°C
Height of transport packing, cm10
Shaft diameter19
Seal typeR-108
All specifications
Pre-order only
Артикул: 13471_19__SIC/SIC__EPDM__304
$31.79
-+Купить
  • Overview
  • Characteristics
  • Reviews0
BTS Engineering
Mechanical seal R-108 is used at temperatures up to + 120°C, a pressure up to 1, 2 MPa and rotation speed of 25 m/sec. Mechanical seal for Wilo pump, K, KM, X, AH, AHP, AH, Calpeda, DAB, Ebara, Grundfos, pump KSB, Allweiler, SALMSON, ACD Cryo, Flygt, IMP Pumps, LOWARA, PENTAX, Foras, Fristam, pump SPERONI, ZENIT, Inoxpa, JL, Johnson pump, KOLMEKS, Pedrollo, SAER, Vulcan, WQ, WQK, pump Tuchenhagen, ALFA LAVAL, Donjoy, Mission Magnum.
Gross weight, kg0.25
Operating temperature-20°C + 150°C
Height of transport packing, cm10
Shaft diameter19
Seal typeR-108
Rotation velocity8 m/s
Rubber typeEPDM
ProducerBTS Engineering
Material of metal part304
Length of transport packing, cm8
Stationary and rotating faceSIC/SIC
Width of transport packing, cm8
Pressure0,6 MPa

Mechanical SealR-108 19, SIC/SIC, EPDM, 304 reviews
