Mechanical seal R-M74 58, SIC/CAR, VITON, 304, G9
$-24.09
Documentation
Download instructions, catalog for Mechanical seal R-M74 58, SIC/CAR, VITON, 304, G9
Overview
Single seal unbalanced R-M74 has the same dimensions as the R-M7N, but with one difference Ale: R-M74 has MULTI unit. The seal is designed to work with petrochemical products maloagressivnymi chemical compounds and substances that are used in the refrigeration industry.
It is used at temperatures from -50 to + 220°C, a pressure up to 2 MPa and 5 rotation speed to 20 m/sec.
Analog mechanical seals: Burgmann M74, Anga V, AESSEAL W07DM, Flowserve Europac 600, Sterling 270, Vulcan 1677.
Mechanical seal for Wilo pump, K, KM, X, AH, AHP, AH, Calpeda, DAB, Ebara, Grundfos, pump KSB, Allweiler, SALMSON, ACD Cryo, Flygt, IMP Pumps, LOWARA, PENTAX, Foras, Fristam, pump SPERONI, ZENIT, Inoxpa, JL, Johnson pump, KOLMEKS, Pedrollo, SAER, Vulcan, WQ, WQK, pump Tuchenhagen, ALFA LAVAL, Donjoy, Mission Magnum.
Characteristics
| Producer | BTS Engineering |
| Shaft diameter | 58 |
| Rubber type | VITON |
| Stationary and rotating face | SIC/CAR |
| Material of metal part | 304 |
| Type of conta-ring | G9 |
| Pressure | 1,6 mPa |
| Rotation velocity | 20 m/s |
| Operating temperature | -20°C +200°C |
| Seal type | R-M74 |
| Analogue for | Burgmann M74, LIDERING LMS11 |
| Gross weight, kg | 0.25 |
| Length of transport packing, cm | 8 |
| Width of transport packing, cm | 8 |
| Height of transport packing, cm | 10 |
How to properly measure a mechanical seal
