Mechanical seal R-T1 1.7/8, SIC/SIC, VITON, 304

ProducerBTS Engineering
Shaft diameter1.7/8
Rubber typeVITON
Material of metal part304
Stationary and rotating faceSIC/SIC
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order only
Vendor code: 13955_1.7/8__SIC/SIC__VITON__304
Specify the price and terms of delivery with the manager

Estimated delivery date: 23.05.2024

$294.30netto
-+Buy

Overview

BTS Engineering
Mechanical seal R-T1 is used at temperatures ranging from -40 to + 120°C, a pressure up to 1 MPa and 7 rotation speed to 13 m/sec. It does not depend on the direction of rotation of the shaft. Has a reliable transmission due to the special design, one hundred and allows you to work under high pressure. Sealing R-T1 is used in pumps, agitators, air compressors, fans and other rotating equipment. Often used in the pulp and paper, petrochemical, food processing, the energy industry. It is used in pumps Mission Magnum & Supreme 2500, MCM250, Halco2500, Double Life250, Mattco, Harrisburg, Cobra, Dragon Derrickk premium 250 Analogs: John Crane Type1, Vulcan Type A5. Mechanical seal for Wilo pump, K, KM, X, AH, AHP, AH, Calpeda, DAB, Ebara, Grundfos, pump KSB, Allweiler, SALMSON, ACD Cryo, Flygt, IMP Pumps, LOWARA, PENTAX, Foras, Fristam, pump SPERONI, ZENIT, Inoxpa, JL, Johnson pump, KOLMEKS, Pedrollo, SAER, Vulcan, WQ, WQK, pump Tuchenhagen, ALFA LAVAL, Donjoy, Mission Magnum.

Characteristics

ProducerBTS Engineering
Shaft diameter1.7/8
Rubber typeVITON
Material of metal part304
Stationary and rotating faceSIC/SIC
Rotation velocity13 m/s
Pressure1.7 MPa
Operating temperature-40°C +200°C
Seal typeR-T1
ApplicationCobra, Dragon Derrickk, Halco, Harrisburg, Mattco, MCM, Mission Pump, Tuthill
Analogue forAESSEAL P05T, AESSEAL P05U, Burgmann MG901/D1-G55, Flowserve 220, Flowserve 51, John Crane 1, LIDERING LRB00U + PF L50, Roten 51A, Sealol 43 CU Long, US SEAL E, Vulcan 22, Vulcan A5
Length of transport packing, cm8
Width of transport packing, cm8
Height of transport packing, cm10
Gross weight, kg0.25

Video Mechanical seal R-T1 1.7/8, SIC/SIC, VITON, 304

How to properly measure a mechanical seal
