Temperature (min), °C-5
ProducerFLUIMAC
Pump capacity, cu.m/hour1.2
Feed height, m70
MaterialPOMc
All specifications
Ukraine: Pre-order onlyPoland: Pre-order onlyGermany: Pre-order only
Vendor code: P0018O-HTTOT1-AB
Specify the price and terms of delivery with the manager

Estimated delivery date: 24.05.2024

$421.61netto
-+Buy

Documentation

Download instructions, catalog for Pneumatic Diaphragm Pump for Acid PHOENIX P18 POM HYTREL+PTFE, 20 l/xv

Overview

FLUIMAC
The PHOENIX series of pneumatic diaphragm pumps manufactured by the Italian company FLUIMAC is represented by a wide range of models for solving production problems of any complexity. PHOENIX diaphragm pumps, with an innovative air separation system, pump chamber geometry and valve system, allow pumping a wide range of aggressive products (concentrated acids, alkalis, solvents, varnishes, glues, liquids with suspended particles up to 10 mm in size, abrasive products, etc.) with viscosities from 6000 to 55000 cPs. The flow part of PHOENIX diaphragm pumps is made of such materials as PVDF, Alu, POMc, PP, AISI 316. The main working elements (diaphragms, ball valves, valve seats) are made of PVDF, Alu, POMc, PP, AISI316, PTFE, NBR, PE, SANTOPRENE, HYTREL. Advantages of FLUIMAC pneumatic diaphragm pumps: - dry suction up to 6 m; - self-priming under water up to 9.8 m; - unlimited dry stroke;

Characteristics

Temperature (min), °C-5
ProducerFLUIMAC
Pump capacity, cu.m/hour1.2
Feed height, m70
MaterialPOMc
Serial number of the pumpPHOENIX
Country of OriginItaly
Input pipe diameter3/8"
Output pipe diameter3/8"
Explosion protectionYes
PumpTypemembrane pneumatic
Drive Typepneumatic
Dry suction height, m5
Material of ball valvesPTFE
Suction capacity (NPSH), m9,8
Max.flow rate, m3/h1.2
Noise level ,dB65
Max.viscosity, cPs10 000
Diametr of the product line3/8"
Max. head, m70
ModelPHOENIX 18
Material of valve seatPOMc
Flow rate, l/min20
Max.air pressure, bar7
Diaphragm material at air sideHYTREL
Diameter of the pneumatic mainline6 mm
Max.temperature, C80
Max.diameter of solid inclusions, mm2,5
Weight, kg1,5
Material of flow channelPOMc
Diaphragm material at water sidePTFE
Availability of spare partsyes
Warranty, months12
Applicationnitric acid, ammonia, butane, hydrogen, viscous liquids, clays, ash, kaolin suspension, urea, carbonate, paints, varnish, saturated amine, oleum, peroxide, sulfur, reverse osmosis systems, alcohol, acetic acid, phenol, formalin, phosphates, phosphoric acid, slag, slip, alkalis, ethylene, ethers
Analogue forAGRAL DDE-030, AGRAL DDE-100, AGRAL DDE-160, AGRAL DDE-300, AGRAL DDE-60, AGRAL DDE-600, AlphaDynamic Ruby, AQUA, AquaViva, Astralpool, Debem BOXER, Debem FOODBOXER, Debem SANIBOXER, DELLMECO DM, DELLMECO DMCX, DEPA DB, DEPA L, DEPA М, DEPA РМ (Р), DOSITEC, Duotek AF Zone 2 Atex, DUOTEK FOOD, DUOTEK SANI, Emec, FWT, Graco Husky, Grundfos, Injecta, Jesco Pump, MILTON ROY, Milwaukee, PRODOSE, ProMinent, Seko, Sera, WILDEN, YAMADA NDP

Categories:Diaphragm pumpsNitric acid pumpPump for liquid glassPump for cream and pastePumps for viscous liquidsGlycerin pumpsAcid pumpsGlue pumpsPumps for paints and varnishesResin pumpsPumps for freonLye pumpsAcid-resistant pumps for aggressive liquidsPumps for aggressive liquids, acid pumpPneumatic PumpsPhoenix diaphragm pumps
