IRG 200-315 (I) Centrifugal pump
- Overview
- Characteristics
- Reviews0
Dry motor pumps of IRG Series are vertical in-line single stage centrifugal pumps. Such kind of body design makes them more resistant to mechanical inclusions contained in feed medium in comparison to the similar pumps with “wet” rotor. “In-line” construction of the pump makes it possible to perform in-place pump dismounting without dismantling the elements of pipeline system.
| Application | water, pressure boosting, circulation, heating, drying chamber, circulating water supply, ice water, cooling tower, irrigation, drying |
| Max.temperature, C | 120 |
| Producer | BTS Engineering |
| Max.flow rate, m3/h | 520 |
| Max. head, meter of water column | 36 |
| PumpType | in-line |
| Installation Type | vertical |
| Input pipe diameter | DN200 |
| Power supply | 3х380 V, 50 Hz |
| Drive Type | electric |
| Power capacity, kW | 55 |
| Material | cast iron |
| Nom.pressure, Mpa | 1,6 |
| Explosion hazard | No |
| Output pipe diameter | DN200 |
| Serial number of the pump | IRG |
| Material of flow channel | cast iron |
| Analogue for | AlfaLaval, ALLWEILER, APV, Aquario, Aquatechnika, ASTA, Bronzoni, Calpeda, Caprari, Cornell, DAB, Varna, DPPumps, Alweller, Ebara, SIHI, Flygt, Foras, |
