Downhole sand-resistant pumps Pedrollo 4SR | page: 2
The design of the hydraulic part of the pump, the composition of the materials used, the front insert in combination with axial movement of impellers and the ability to pump water with a sand content of up to 150 g/m3 provide reliable protection of the pump against seizure and wear caused by the ingress of sand.
Technical specifications
- Productivity up to 375 l /min (22,5 m3/hour).
- Head up to 525 m.
Application limits |
|
 |
Scope and installation |
| Recommended for pumping clean water with a sand content of no more than 150 g/m3. Due to their high efficiency and reliability, they are suitable for household use, utilities and industry, for the organization of water supply in combination with systems maintaining pressure, irrigation, increasing pressure in the network. In washing plants and systems fire extinguishing, etc. |
Design characteristics |
|
Pre-order only
Vendor code: 49480223WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 2 |
| Feed height, m | 150 |
| Power capacity, kW | 1,5 |
$685.04
Pre-order only
Vendor code: 49480223WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 2 |
| Feed height, m | 150 |
| Power capacity, kW | 1,5 |
$653.10
Pre-order only
Vendor code: 49480233WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 2 |
| Feed height, m | 216 |
| Power capacity, kW | 2,2 |
$842.18
Pre-order only
Vendor code: 49480233WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 2 |
| Feed height, m | 216 |
| Power capacity, kW | 2,2 |
$797.97
Pre-order only
Vendor code: 49480406WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 32 |
| Power capacity, kW | 0,55 |
$503.88
Pre-order only
Vendor code: 49480406WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 32 |
| Power capacity, kW | 0,55 |
$503.88
Pre-order only
Vendor code: 49480408WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 40 |
| Power capacity, kW | 0,75 |
$476.32
Pre-order only
Vendor code: 49480408WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 40 |
| Power capacity, kW | 0,75 |
$473.88
Pre-order only
Vendor code: 49480412WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 63 |
| Power capacity, kW | 1,1 |
$532.79
Pre-order only
Vendor code: 49480412WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 63 |
| Power capacity, kW | 1,1 |
$532.79
Pre-order only
Vendor code: 49480415WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 81 |
| Power capacity, kW | 1,5 |
$613.83
Pre-order only
Vendor code: 49480415WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 81 |
| Power capacity, kW | 1,5 |
$581.92
Pre-order only
Vendor code: 49480422WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 116 |
| Power capacity, kW | 2,2 |
$751.34
Pre-order only
Vendor code: 49480422WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 116 |
| Power capacity, kW | 2,2 |
$707.12
Pre-order only
Vendor code: 49480430WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 157 |
| Power capacity, kW | 3 |
$915.84
Pre-order only
Vendor code: 49480440WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 205 |
| Power capacity, kW | 4 |
$1,379.88
Pre-order only
Vendor code: 49480454WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 4 |
| Feed height, m | 270 |
| Power capacity, kW | 5,5 |
$1,652.43
Pre-order only
Vendor code: 49480606WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 19 |
| Power capacity, kW | 0,55 |
$464.05
Pre-order only
Vendor code: 49480604WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 19 |
| Power capacity, kW | 0,55 |
$494.75
Pre-order only
Vendor code: 49480606WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 29 |
| Power capacity, kW | 0,75 |
$461.60
Pre-order only
Vendor code: 49480609WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 44 |
| Power capacity, kW | 1,1 |
$515.62
Pre-order only
Vendor code: 49480609WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 44 |
| Power capacity, kW | 1,1 |
$515.62
Pre-order only
Vendor code: 49480613WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 61 |
| Power capacity, kW | 1,5 |
$604.02
Pre-order only
Vendor code: 49480613WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 61 |
| Power capacity, kW | 1,5 |
$572.09
Pre-order only
Vendor code: 49480617WLA1
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 79 |
| Power capacity, kW | 2,2 |
$721.85
Pre-order only
Vendor code: 49480617WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 79 |
| Power capacity, kW | 2,2 |
$677.66
Pre-order only
Vendor code: 49480624WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 112 |
| Power capacity, kW | 3 |
$883.93
Pre-order only
Vendor code: 49480632WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 149 |
| Power capacity, kW | 4 |
$1,131.89
Pre-order only
Vendor code: 49480643WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 212 |
| Power capacity, kW | 5,5 |
$1,448.62
Pre-order only
Vendor code: 49480658WLA
| Diameter of pump | 4" (100 mm) |
| Producer | Pedrollo |
| Pump capacity, cu.m/hour | 6 |
| Feed height, m | 280 |
| Power capacity, kW | 7,5 |
$1,902.86
