Mechanical seal R-260TS
Mechanical seal R-260TS
Double mechanical seal R-260TS is a bellows type with a conical spring. The R-260TS mechanical seal is lubricated and cooled by a seal fluid (usually oil) under a pressure exceeding the pressure of the working medium by 0.1...0.2 MPa.
Application: Tsurumi KTZ Series submersible pumps.
Type: USSEAL VGM562, Lidering TS-H2530/3035, HT-2530N, HT-3035N, HT-3540N, HT-4550N.
Temperature: -40°~150°
Pressure: ≤0.8 MPa
Speed: ≤10 m/s
Materials:
- Rotary ring: SIC;
- Stationary ring: SIC;
- Bellows: NBR/VITON;
- Spring: SS304/SS316;
- Metal parts: SS304/SS316.
Pre-order only
Vendor code: 1042811
| Shaft diameter | 20 |
| Producer | BTS Engineering |
| Stationary and rotating face | SIC/SIC/SIC/SIC |
| Material of metal part | AISI 304 stainless steel |
| Pressure | 0,8 MPa |
$107.95
$-5.69
$113.64
Pre-order only
Vendor code: 1042812
| Shaft diameter | 25 |
| Producer | BTS Engineering |
| Stationary and rotating face | SIC/SIC/SIC/SIC |
| Material of metal part | AISI 304 stainless steel |
| Pressure | 0,8 MPa |
$134.94
$-7.10
$142.04
Pre-order only
Vendor code: 1042813
| Shaft diameter | 30 |
| Producer | BTS Engineering |
| Stationary and rotating face | SIC/SIC/SIC/SIC |
| Material of metal part | AISI 304 stainless steel |
| Pressure | 0,8 MPa |
$161.94
$-8.53
$170.47
Pre-order only
Vendor code: 1042814
| Shaft diameter | 35 |
| Producer | BTS Engineering |
| Stationary and rotating face | SIC/SIC/SIC/SIC |
| Material of metal part | AISI 304 stainless steel |
| Pressure | 0,8 MPa |
$188.92
$-9.95
$198.87
Pre-order only
Vendor code: 1042815
| Shaft diameter | 45 |
| Producer | BTS Engineering |
| Stationary and rotating face | SIC/SIC/SIC/SIC |
| Material of metal part | AISI 304 stainless steel |
| Pressure | 0,8 MPa |
$242.91
$-12.79
$255.70
